In modern distributed systems, Identity is the Perimeter. While many choose managed services like Auth0 or Okta, enterprise requirements often demand a custom Identity Provider (IdP) for full control over data sovereignty, token customization, and integration with legacy user stores.

In the .NET ecosystem, OpenIddict has emerged as the most flexible and powerful framework for building standards-compliant OIDC/OAuth2 servers.

Why OpenIddict?

Unlike traditional frameworks that dictate how your database or UI should work, OpenIddict focus purely on the protocol logic.

• DB Agnostic: Supports EF Core, MongoDB, or your custom persistence layer.
• Low Level: You own every endpoint (Authorize, Token, UserInfo).
• Standards Compliant: Implements OIDC, OAuth2, and advanced specs like Pushed Authorization Requests (PAR).

The Architecture of an IdP

graph TD
    Client[Client App: SPA/Mobile]
    Gateway[API Gateway]
    OIDC[OpenIddict IdP]
    DB[(User & Token DB)]
    API[Protected Microservices]

    Client -- "1. Authenticate" --> OIDC
    OIDC -- "2. Issue JWT" --> Client
    Client -- "3. Bearer Token" --> Gateway
    Gateway -- "4. Introspect/Validate" --> OIDC
    Gateway -- "5. Forward Req" --> API

Key Implementation Steps

1. Configuring the OpenIddict Core

In your startup configuration, you define which OIDC features you want to enable. For a modern enterprise setup, we typically enable Authorization Code Flow with PKCE.

services.AddOpenIddict()
    .AddCore(options =>
    {
        options.UseEntityFrameworkCore()
               .UseDbContext<ApplicationDbContext>();
    })
    .AddServer(options =>
    {
        // Enable endpoints
        options.SetAuthorizationEndpointUris("/connect/authorize")
               .SetTokenEndpointUris("/connect/token")
               .SetUserinfoEndpointUris("/connect/userinfo");

        // Enable Grant Types
        options.AllowAuthorizationCodeFlow()
               .RequirePcke();

        // Register Signing/Encryption Credentials
        options.AddDevelopmentEncryptionCertificate()
               .AddDevelopmentSigningCertificate();

        // Register ASP.NET Core integration
        options.UseAspNetCore()
               .EnableTokenEndpointPassthrough()
               .EnableAuthorizationEndpointPassthrough();
    });

2. Mastering Token Customization

One of the main reasons to use a custom IdP is to inject domain-specific claims into the JWT. This reduces the number of database calls your microservices need to make.

[HttpPost("~/connect/token")]
public async Task<IActionResult> Exchange()
{
    var request = HttpContext.GetOpenIddictServerRequest();
    if (request.IsPasswordGrantType())
    {
        var user = await _userManager.FindByNameAsync(request.Username);

        // Create the principal
        var principal = await _signInManager.CreateUserPrincipalAsync(user);

        // Add custom claims that will be persisted in the JWT
        principal.SetClaim("organization_id", user.OrganizationId)
                 .SetClaim("tier", user.SubscriptionTier);

        // Define which claims are included in which tokens
        principal.SetDestinations(static claim => claim.Type switch
        {
            "organization_id" => [Destinations.AccessToken, Destinations.IdentityToken],
            _ => [Destinations.AccessToken]
        });

        return SignIn(principal, OpenIddictServerAspNetCoreDefaults.AuthenticationScheme);
    }
}

3. Securing the Flow with PKCE

PKCE (Proof Key for Code Exchange) is mandatory for SPAs and mobile apps. It prevents authorization code injection attacks by requiring a cryptographic secret (code_verifier) to be exchanged for the token.

sequenceDiagram
    participant App as SPA/Mobile
    participant OIDC as OpenIddict Server

    App->>App: Generate Code Verifier & Challenge
    App->>OIDC: /authorize?code_challenge=xyz
    OIDC-->>App: Authorization Code
    App->>OIDC: /token?code=abc&code_verifier=xyz
    OIDC->>OIDC: Verify Challenge
    OIDC-->>App: Access Token

Lessons from the Trenches

• Rotation is Key: Never use development certificates in production. Automate your certificate rotation using Azure Key Vault or AWS Secrets Manager.
• The “UserInfo” Bottleneck: Don’t put too much in the JWT. Use the UserInfo endpoint for non-essential user profile data to keep your tokens small and fast.
• Introspection for Revocation: If you need the ability to revoke tokens immediately (e.g., if a user is fired), use Token Introspection instead of purely stateless JWT validation.

Conclusion

Building an IdP with OpenIddict is a serious undertaking, but it provides the ultimate flexibility for complex enterprise architectures. It allows you to transform “Identity” from a hurdle into a strategic asset.
